Shop
Sold out
Swidget S16008WA Dry Contact Timer Switch, 20/40/60 Minute Programmable Wall Control Module
SKU:
PANS16008WA
| Product Number: | S16008WA (W=white) |
|---|---|
| Input Power Rating: | 125VAC, 5A |
| LED/CFL Load Rating: | 300W |
| Incandescent Load Rating: | 600W |
| Horsepower Load Rating: | 0.3 HP |
| Wiring Type: | Pre-stripped wire leads (Line/Neutral/Switch) #16 AWG (Stranded), Ground screw |
| Switch Configuration: | Single pole, dry contact |
| Testing and Code Compliance: | UL1310/UL60730-1 CSA 22.2 #223/E60730-1 (Canada and US) |
| Flammability: | UL94 5VA |
| Environmental: | Indoor installation only |
| Operating Temperature: | 14F to 104F (-10C to 40C) |
| Insert Voltage Output: | Nominal 5VDC (+/- 5%) |
| Insert DC Protection: | CLASS 2 – Current limiting and thermal shutdown protection |
| Insert Current Output: | Constant current maximum 2.0A |
Tesa 51026 PET Cloth Wire Harness Tape for Automotive Wiring Protection
SKU:
TES51026
| Elongation at break | 40 % |
|---|---|
| Type of adhesive | acrylic |
| Tensile strength | 275 N/cm |
| Total thickness | 260 µm |
| Backing material | PET cloth |
| Abrasion resistance (5mm mandrel) | Class D (acc. to LV312) |
| Temperature resistance (3000h) | 150 °C |
| Temperature resistance min. | -40 °C |
| Unwind force (roll width ≤ 9mm) | 11 N/roll (30 m/min) |
| Unwind force (roll width > 9mm) | 11 N/roll (30 m/min) |
| Noise damping (decibel) | Class A (acc. to LV312) dB |
| Abrasion resistance (10mm mandrel) | Class D (acc. to LV312) |
| Adhesion to steel | 5.5 N/cm |
Tesa 51036 PET Cloth Wire Harness Tape, Automotive Grade Abrasion Resistant Electrical Wiring Tape
SKU:
TES51036
| Carrier/Backing: | PET Cloth |
|---|---|
| Adhesive: | acrylic |
| Thickness: | 10.2 mils (carrier, adhesive) |
| Adhesion: | 26.9 ounces per inch (to stainless steel test panel) |
| Service/Operating Temperature: | -40°F to 302°F |
| Elongation: | 45% |
| Abrasion resistance (5mm mandrel): | Class D (acc. to LV312) |
| Flame resistance as composite: | Class B (acc. to LV312) |
| Tensile strength | 275 N/cm |
| Total thickness | 260 µm |
