Panasonic FV-15NLFS1H WhisperFresh Select Fresh Air Supply Fan, 50-150 CFM
| Model number: |
FV-15NLFS1H |
|---|---|
| Fan Type: |
Fan Only |
| Air Volume Supply (CFM): |
@0.2 and 0.3= 50 ,60 ,70 ,80 ,90 ,100 ,110 ,130 ,150@0.4=50 ,60 ,70 ,80 ,90 ,100 ,110 ,130 ,130 |
| Power Consumption (Watts): |
50 CFM=8.2 ,60=9.3 ,70=10.0 ,80=12.4 ,90= 13.5 ,100=15.3 ,110=16.7 ,130=22.6 ,150=27.3 |
| Energy Efficiency (CFM/Watt): |
50 CFM=7.40 ,60 CFM=7.58 ,70 CFM=7.64 ,80 CFM=7.83 ,90 CFM=7.61 ,100 CFM ,7.45 ,110 CFM=7.05 ,130 CFM=6.30 ,150 CFM=5.59 |
| Current (Amps): |
50=0.20 ,60=0.15 ,70=0.16 ,80= 0.18 ,90=0.20 ,100=0.23 ,110=0.25 ,130=0.33 ,150 ,0.41 |
| Power Rating (V/Hz): |
120/60 |
| Motor Type (AC/DC): |
ECM |
| ENERGY STAR® Certified: |
Yes |
| Other Approved Codes and Standards: |
ASHRAE 62.2 ,LEED CA Tittle 24 |
| Duct Diameter: |
6 inch |
| Mounting Options: |
Vertical /Horizontal |
| Ventilation Design Approach: |
Supply Ventilation ,Balance Ventilation when used with an exhaust fan |
| Warranty: |
6 year ECM motor/3 year parts |
| Industry: |
Residential ,Light Commercial |
| Radiation Damper Available: |
N/A |
| Available Options |
Air Supply Fan – FV15NLFS1H |
Panasonic FV-CSVK1 WhisperGreen Select Condensation Sensor Module
| Advanced Features: |
Humidity Control |
|---|---|
| Construction Type: |
single Family/ Manufactured Housing. Multi-Family. Hospitality/Assisted Living/ Student Housing. Renovation/Remodeling |
| Humidity/Condensation Sensor: |
Yes |
| Industry: |
Residential. Light Commercial. |
| Product Family Name: |
WhisperGreen Select Fan. WhisperGreen Select Fan/Light. |
| Available Options |
Condensation Sensor Module – FVCSVK1 |
Panasonic FV-JD Transfer Register Box For WhisperValue Fans
| Advanced Features: |
Single Speed |
|---|---|
| CFM: |
80-110. 120-150 |
| Construction Type: |
single Family/ Manufactured Housing. Multi-Family. Hospitality/Assisted Living/ Student Housing. Renovation/Remodeling |
| Ventilation Design Approach: |
Continuous Ventilation. Spot Ventilation |
| Duct Diameter: |
3". 4" |
| Fan Type: |
Fan only. Fan/Light CFL |
| Industry: |
Residential. Light Commercial |
| Installation: |
Wall Mount |
| Mounting Options: |
Ceiling Mount. Wall Mount(UL). Tub/Shower(UL) |
| Product Family Name: |
WhisperValue DC. WhisperValue Lite |
Panasonic FV-MSVK1 WhisperGreen Select Motion Sensor Module
| Advanced Features: |
Motion Sensor |
|---|---|
| Construction Type: |
single Family/ Manufactured Housing. Multi-Family. Hospitality/Assisted Living/ Student Housing. Renovation/Remodeling |
| Industry: |
Residential. Light Commercial. |
| Product Family Name: |
WhisperGreen Select Fan. WhisperGreen Select Fan/Light. |
| Available Options |
Motion Sensor Module – FVMSVK1 |
Panasonic FV-NLF46RES Recessed Inlet with Light
| Additional info: |
*Only for Lamp |
|---|---|
| Advanced Features: |
Single Speed |
| California Title 24 Compliant: |
Yes |
| Color Rendering Index: |
92 |
| Color Temperature (Kelvin): |
2 ,700 |
| Construction Type: |
Single Family/Manufactured Housing. Multi-Family. Hospitality/Assisted Living/Student Housing. Renovation/Remodeling. |
| Ventilation Design Approach: |
Continuous Ventilation. Spot Ventilation. |
| ENERGY STAR® Certified: |
Yes |
| Fan Type: |
Fan/Light – LED |
| Housing Collar Opening (Inches): |
6" Round |
| Industry: |
Residential. Light Commercial. |
| Inlet: |
Inlet Unit |
| Lamp Model # (Green Creative): |
11BR30G4DIM/927/GU24 |
| Lamp Watts |
1 x 11 |
| Lumens (lm): |
750 |
| Lumens Per Watt (LPW): |
69 |
| Mfg in ISO 9001 Certified Facility: |
Yes |
| Motor Type (AC/DC): |
N/A |
| Mounting Options: |
Ceiling Mount (UL). Tub/Shower (UL) |
| Power Rating (V/Hz): |
120/60 |
| Product Family Name: |
Recessed Inlet |
| Rated Life (hours): |
25 ,000 |
| Trim Outer Diameter (Inches): |
7-1/4" Round |
| Type of Lamp Socket: |
GU24 |
| UL tub/Shower Enclosure: |
Yes |
Panasonic FV-VS15VK1 WhisperGreen Select Multi-Speed Module
| Advanced Features: |
Multi-Speed. Delay Timer. |
|---|---|
| Construction Type: |
single Family/ Manufactured Housing. Multi-Family. Hospitality/Assisted Living/ Student Housing. Renovation/Remodeling |
| Industry: |
Residential. Light Commercial. |
| Product Family Name: |
WhisperGreen Select Fan. WhisperGreen Select Fan/Light. |
| Available Options |
Multi-Speed Module – FVVS15VK1 |
Panasonic FV-VS43R 4″ to 3″ Duct Adaptor
| Advanced Features: |
Single Speed |
|---|---|
| CFM: |
80-110. 120-150 |
| Construction Type: |
single Family/ Manufactured Housing. Multi-Family. Hospitality/Assisted Living/ Student Housing. Renovation/Remodeling |
| Ventilation Design Approach: |
Continuous Ventilation. Spot Ventilation |
| Duct Diameter: |
3". 4" |
| Fan Type: |
Fan only. Fan/Light CFL |
| Industry: |
Residential. Light Commercial |
| Installation: |
Wall Mount |
| Mounting Options: |
Ceiling Mount. Wall Mount(UL). Tub/Shower(UL) |
| Product Family Name: |
WhisperValue DC. WhisperValue Lite |
